RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved With Codes

RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved With Codes

  • RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes
  • RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes
RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes
Product Details:
Place of Origin: Guangzhou, China
Brand Name: Rich Packing
Certification: CE/ISO 9001/SGS
Model Number: RQ-ZHL-260W
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden case
Delivery Time: 25-35 working days
Payment Terms: L/C, D/P, T/T
Supply Ability: 30 pcs/month
Contact Now
Detailed Product Description
Pressure: Air Consumption:120-200 L/min Speed: 260 Carton/min
Power Supply: 220V
High Light:

high speed packaging machines

,

automatic capsule filler



1. The machine body is made of stainless steel or nickel-chromium plated material, and the welding position is tempered. The chemical performance is stable. It has the advantages of corrosion resistance, non-toxicity, harmlessness and durability.

2. RQ-ZH-260W cartoning machine adopts the latest full servo vibration blanking technology, which has faster blanking speed and higher accuracy, up to 260 cartons per minute at the fastest.



RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes 0

After-sale Provide Engineers Available To Service Machinery Overseas
Cartoning Machine Models 120W 260W 450W
Power 0.75 Kw 5 Kw 4.5 Kw
Capacity 120 Carton/Min 260 Carton/Min 450 Carton/Min
Dimension 3100*1100*1550 mm 6800*1600*1860 mm 4800*1800*2000 mm
Weight 1600 Kg 3400 Kg 5500 Kg



Spare Parts Name Specification Qty. Manufacturer
Servo Motor 400W MHMD042G1U 1 Panasonic
Servo Driver 400W MBDHT2510E 1 Panasonic
Main Motor R17DT80N4 1.1KW/220V/380V 1 Germany SEW
Vacuum Pump VT4.40 1 BECKER
Frequency Converter FC-051P1K5S2E20H 1 Danfoss
Air Circuit Breaker DZ47-D63/2P 1 Yaohua
PLC Smart ST40 1 Siemens
Emergency Stop Button ZB2-BE102C 1 France Schneider





1.Rotating quadrilateral double planetary wheel structure and pre-forming devices

ensure the forming effect of the carton and improve the working efficiency

RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes 1

2.Double clutch design

Double protection to ensure equipment and personnel safety

RQ-ZH-260W Automatic Horizontal Cartoning Machine All Spare Part Are Engraved  With Codes 2
