| Place of Origin: | Guangzhou, China |
| Brand Name: | Rich Packing |
| Certification: | CE ISO SGS |
| Model Number: | NJP-800C |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | $15000-21000/pc |
| Packaging Details: | Standard export wooden case |
| Delivery Time: | 20-30 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30 pcs/month |
| Name: | High Speed Capsule Filling Hard Gelatin Machinery CE ISO SGS Certification | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support |
|---|---|---|---|
| Dimension(l*w*h): | 865*855*1900(mm) | Capacity: | 48000 Capsules/h |
| Noise: | <75DB(A) | Capsule Size: | 000 00 0 1 2 3 4 5 |
| Vacuum: | 20m3/h-0.04-0.08Mpa | Weight: | 900KG |
| Voltage: | 220V/380V 50 Hz | Warranty: | 1 Year |
| Total Power: | 5000w | ||
| Highlight: | automatic capsule filler,auto capsule filling machine |
||
High Speed Capsule Filling Hard Gelatin Machinery CE ISO SGS Certificatio
| Production capacity | 48000 pcs/h |
| Net weight of machine | 900Kg |
| Overall size of machine | 865×855×1900(mm) |
| Power | 380/220V 50Hz |
| Total power | 5KW |
| No.of segment bores | 6 |
| Vacuum | 20m3/h-0.04-0.08Mpa |
| Dust collector | 17.6Kpa 180m3/h |
| Noise | <75DB(A) |
| Making rate | Empty capsule 99.9% Full capsule 99.8% |
| Applicable capsule | 00,0,1,2,3,4,5# |
| Filling error | Western medicine:±3% Chinese medicine:±4% |
| Applicable product | Power,granule,pellet,tablet |
Product details:
Production workshop:
Global after-sales service:
1.The capsule filler machine has 6 technological innovations and 2 invention patents.
2.Pharmacy capsule filling equipment can fill powder, granules and other materials into hollow capsules (000#, 00#, 0#, 1#, 2#, 3#, 4#, 5#).
3.The capsule filler machinery is precision mold concentricity, zero deviation, ensure that the capsule is not wiping, no damage.
4.Automatic rejection device, improve the charging efficiency ,the capsule filling equipment is suitable to pharmacy and health care food manufacture.
5.The capsule filling machine of Guangdong Rich Packing Packing Machinery Co. Ltd. has reasonable design,modular structure, easy operation and lower failure rate.
The data comes from Guangdong Rich Packaging Machinery Co., Ltd
6.Rotary of capsule filling machine design to obtain a patent for utility model, the sealing ring using imported SIL silicone rubber, effectively prevent powder into the internal turntable, good sealing performance, no dust overflow
pollution;
7.Transverse biaxial adapt PTFE oil-less bearing, no need refueling; modular structure, equipped with jog operation, convenient maintenance and cleaning, replacement of mold only 15 minutes,our capsule filling machine is newest.
8.Guangdong Rich Packing Machinery Co. Ltd. has big design deparment of capsule filling machine,the filling mechanism obtains the national new patent, adopts the three-dimensional adjustment, makes the metering plate evenly force, the
adjustment volume is precise and quick, and the powder recovery device is added, the recycling rate is 100%, which reduces the waste and improves the economic benefit.
9.The separation device of pharmacy machinery has been innovated to separate the powder from the waste capsule and avoid the pollution of the reclaimed powder. (Optional)
10All the parts of the contact drug of pharmacy equipment are made of stainless steel 316, and the waste device adopts seven lines of aero aluminum.
