Product Details:
Place of Origin: Guangzhou, China
Brand Name: Rich Packing
Certification: CE ISO SGS
Model Number: RQ-ZH-120L
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiated
Packaging Details: Standard export wooden case
Delivery Time: 20-30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 pcs/month
Contact Now
Detailed Product Description
Name: Automatic Cartoning Packing Machine For Tablet Capsule Blister Card Speed: 35-125 Carton/min
Total Power: 1.10 KW Size Range Of Carton: L(65-150)*W(35-85)*H(12-45)mm
Range Of Folding Times Of Instructions: 1-4 Fold Power Supply: 220/380V 50Hz
Carton Weight: 240-360g/㎡ Size Range Of Instructions: L(78-250)*W(85-170)mm
Instructions Weight: 60-70g/㎡ Pressure Intensity: ≥0.6MPa
Air Consumption: 120-160 L/min Overall Size Of Machine: 2150*1140*1800㎜
Net Weight Of Machine: 1500kg
High Light:

auto cartoner machine

,

carton packing machine

Automatic Cartoning Packing Machine for Tablet Capsule Blister Card



Introduction of cartoning machine:

The cartoning box packing machien is high technology product incorporates pneumatic - photo - electro - mechanic with improves work efficiency and reduces labor cost.This automatic vertical cartoning machine is the preferred products for small and medium sized production in pharmaceutical manufacturing,chemical industry, electronic products and food industry, it meets the requirements of GMP.
The cartoning machine is a kind of packaging machinery, which includes automatic cartoning machine, medicinal cartoning machine and so on.



Features of cartoning box packing machine:



1. Automatic vertical cartoning packing machine can packed various products such as aluminum plastic plate and aluminum aluminum plate, electronic cigarette,facial cleanser,ointment,Sealed pouch various bottled products.

2. All the materials of cartonging machine are made of stainless steel or nickel-chromium plated material, with stable chemical performance, corrosion resistance, non-toxicity and harmlessness. The welding position of cartoning machine is

tempered and durable.

3. The cartoning box packing machine accessories adopt well-known brands, such as Siemens, Baker, Omron, etc
4. The automatic vertical cartoning packing machine produced by Guangdong Rich Packing Machinery Co.,Ltd has stable performance and is suitable for 24 hours operation.

Model RQ-ZHL-12OL
Speed 35-125 carton/min
Total power 1.10 KW
Power supply 220/380V 50Hz
Requirements of carton size range of carton:L(65-150)*W(35-85)*H(12-45)mm
  carton weight:240-360g/㎡
Requirements of instructions size range of instructions:L(78-250)*W(85-170)mm
  range of folding times of instructions:1-4 fold
  instructions weight:60-70g/㎡
Pressure pressure intensity:≥0.6MPa
  air consumption:120-160 L/min
Overall size of machine 2150*1140*1800㎜
Net weight of machine about 1500kg



Automatic Cartonator Packing Machine , High Speed Tablet Packing Machine 0



Product details:

Automatic Cartonator Packing Machine , High Speed Tablet Packing Machine 1

Production workshop:

Automatic Cartonator Packing Machine , High Speed Tablet Packing Machine 2
Our client:

Automatic Cartonator Packing Machine , High Speed Tablet Packing Machine 3

Automatic Cartonator Packing Machine , High Speed Tablet Packing Machine 4
