Full Automatic Blister Plate Tea Bag Cartoning Box Packing Machine
Detailed Product DescriptionName:RQ-ZHL-120W Free Spare Parts Automatic Coffee Stick Pack Cartoning MachineSpeed:34-119 Carton/minTotal Power:748wSize Range Of Carton:L(70-185)*W(35-90)*H(14-50)mmRange Of Folding Times Of Instructions:Max 4 FoldsPower Supply:200/380V 50HzCarton Weight:251-350g/?OSi…
- Estimated Delivery : 7 Days Fast Delivery
- Certification : cGMP CE ISO SGS and etc
- After-Sales Provided : Engineers available to service machinery overseas.
| Detailed Product Description | |||
|---|---|---|---|
| Name: | RQ-ZHL-120W Free Spare Parts Automatic Coffee Stick Pack Cartoning Machine | ||
| Speed: | 34-119 Carton/min | ||
| Total Power: | 748w | ||
| Size Range Of Carton: | L(70-185)*W(35-90)*H(14-50)mm | ||
| Range Of Folding Times Of Instructions: | Max 4 Folds | ||
| Power Supply: | 200/380V 50Hz | ||
| Carton Weight: | 251-350g/?O | ||
| Size Range Of Instructions: | L(78-250)*W(90-170)mm | ||
| Instructions Weight: | 62-70g/?O | ||
| Pressure Intensity: | ??0.601MPa | ||
| Air Consumption: | 115-160 L/min | ||
| Overall Size Of Machine: | 3110*1100*1550?L | ||
| Net Weight Of Machine: | 1610kg | ||
| Highlight: |
Cartoning Box Packing Machine, 119pcs/min Cartoning Box Packing Machine, 120W Horizontal Cartoning Machine |
||
Full Automatic Blister Plate Tea Bag Cartoning Box Packing Machine
Rich Packing: The RQ company has been operating in the pharmaceutical packaging machinery industry for more than 27 years, and has cooperated with customers all over seven continents and five oceans.These ZH-120W horizontal cartoning machine, is a variety of products developing by RQ Machinery.
Wide range of application: RQ-120W can automated fast cartoning hard shell capsule aluminum plastic plate, soft sachet, tea sachet, adult condoms, e-vape pen, soap, hard bottles, mask for ladies and others. This horizontal cartoning machine has a wide range of application scenarios. According to the your actual needs, you can link it with counting tablet machine, aluminum plastic blister packaging machine, sealer machine, and coating machine for medical production.
One-stop whole process: This Horizontal 120W cartoning machine can meets the requirements of ordinary products, but also suit to big bag and hard bottle box packing.These horizontal cartoning machine adopts one-stop whole process system solution. All production procedures are controlled by PLC, including packing, inspection, instruction, tongue insertion, glue sealing, box sealing, printing and so on.This machine adopts the forward push type feeding device, in the production process, the operator can control the production process, if there is a problem, convenient and timely solution.
| Detailed Product Description | |||
|---|---|---|---|
| Model type | RQ-ZH-12OW | ||
| Speed of its capacity | 25-128 cartons/min | ||
| Total power w | 749 | ||
| power supply V/Hz | 205/380V 50Hz | ||
| Requirements to cartons | size range from :L(70.0-185)*W(35.0-90)*H(14-50.0)mm | ||
| weight from:245-345g/?O | |||
| Requirements of instructions mm | range of instructions from:L(75-250)*W(91-170)mm | ||
| range of foldings :1-4 folds | |||
| instructions weight from :58-72g/?O | |||
| data of Pressure | pressure data intensity:≥0.610MPa | ||
| air consumption:121-160 L/min | |||
| Overall size of this machine | 4,300*1,100*1,555?L | ||
| Net weight of this machine | about 1,579kg | ||
| Detailed Product Description | ||||
|---|---|---|---|---|
| model | 120L | 120W | 260W | 450W |
| capacity /min | 35-125 | 35-125 | 260 | 450 |
| paper requirement | L:70-185mm, W:35-90mm, H:14-50mm 250-360g/?O | |||
